TR4 Plate AK - BODY AND FITTINGS: FLOORS REAR WINGS INNER AND OUTER AND REAR BODY PANELS.

  Plate No. Part No. Description and Comments No Per Unit Price Add to Cart
AK1
850344

CLICK FOR
MORE INFO

Post 'A', inner assembly R.H.

1
Ex VAT: £70.11
Inc VAT: £84.13

AK2
850343

CLICK FOR
MORE INFO

Post 'A', inner assembly L. H.

1
Ex VAT: £68.00
Inc VAT: £81.60

AK3
850270

CLICK FOR
MORE INFO

Post 'A', outer assembly R.H.

This item has been superceded by 813101 - see below

1
813101

CLICK FOR
MORE INFO

A POST OUTER RH

Fitted up to end of TR6 production 1976. Pierced for one courtesy light switch.
Remarks: Fitted up to Body No. 22343CT only

1
Ex VAT: £89.50
Inc VAT: £107.40

AK4
850269

CLICK FOR
MORE INFO

Post 'A', outer assembly L.H.

This item has been superceded by XKC510 - see below

1
XKC510

CLICK FOR
MORE INFO

A POST OUTER LH TR6 LATE

Fitted from commission number CR5001/CF12501 1973 to 1976. Pierced for two courtesy light switch.
Remarks: Fitted up to Body No. 22343CT only

1
Ex VAT: £68.33
Inc VAT: £82.00

AK4A
807422

CLICK FOR
MORE INFO

Post 'A', outer assembly R.H.

This item has been superceded by 813101 - see below

1
813101

CLICK FOR
MORE INFO

A POST OUTER RH

Fitted up to end of TR6 production 1976. Pierced for one courtesy light switch.
Remarks: Fitted from Body No.23344CT and future

1
Ex VAT: £89.50
Inc VAT: £107.40

AK4B
807421

CLICK FOR
MORE INFO

Post 'A', outer assembly L.H.

This item has been superceded by XKC510 - see below

1
XKC510

CLICK FOR
MORE INFO

A POST OUTER LH TR6 LATE

Fitted from commission number CR5001/CF12501 1973 to 1976. Pierced for two courtesy light switch.
Remarks: Fitted from Body No.23344CT and future

1
Ex VAT: £68.33
Inc VAT: £82.00

AK5
564807

CLICK FOR
MORE INFO

Panel, sill, inner assembly R.H.

1
Ex VAT: £40.83
Inc VAT: £49.00

AK6
850122

CLICK FOR
MORE INFO

Panel, sill, inner assembly L.H.

This left hand inner sill part number 850122 has tags attached to secure the wiring down the left side of the car and is suitable for TR250, 5 and 6 as the wiring on these cars...

1
Ex VAT: £40.83
Inc VAT: £49.00

AK7
850282

CLICK FOR
MORE INFO

Panel, sill, outer R.H.

1
Ex VAT: £60.67
Inc VAT: £72.80

AK8
850281

CLICK FOR
MORE INFO

Panel, sill, outer L.H.

1
Ex VAT: £60.67
Inc VAT: £72.80

AK9
750163

CLICK FOR
MORE INFO

Retainer, seal, sill outer panel

2
Ex VAT: £5.67
Inc VAT: £6.80

AK9A
750087

CLICK FOR
MORE INFO

Filler, sill end, front R.H.

1
Ex VAT: £4.42
Inc VAT: £5.30

AK1O
750086

CLICK FOR
MORE INFO

Filler, sill end, front L.H.

1
Ex VAT: £4.42
Inc VAT: £5.30

AK10A
750048

CLICK FOR
MORE INFO

Filler, sill end, rear R.H.

1
Ex VAT: £4.42
Inc VAT: £5.30

AK11
750047

CLICK FOR
MORE INFO

Filler, sill end, rear L.H.

1
Ex VAT: £3.50
Inc VAT: £4.20

AK12
850276

CLICK FOR
MORE INFO

Post 'B' assembly R.H.

TR4-4A complete B-Posts, part numbers 850275 and 850276 are available as separate front and back parts as well as a complete assembly. If preferred please order both front and back parts listed below to make a...

1
Ex VAT: £160.00
Inc VAT: £192.00

AK13
850275

CLICK FOR
MORE INFO

Post 'B' assembly L.H.

TR4-4A complete B-Posts, part numbers 850275 and 850276 are available as separate front and back parts as well as a complete assembly. If preferred please order both front and back parts listed below to make a...

1
Ex VAT: £160.00
Inc VAT: £192.00

AK13A
611572

CLICK FOR
MORE INFO

Reinforcement, sill to 'B' post R.H.

Use 611571.

1
AK14
611571

CLICK FOR
MORE INFO

Reinforcement, sill to 'B' post L.H.

1
Ex VAT: £13.00
Inc VAT: £15.60

AK15
611570

CLICK FOR
MORE INFO

Gusset, sill to 'B' post

2
Ex VAT: £4.61
Inc VAT: £5.53

AK16
850426

CLICK FOR
MORE INFO

Wheelarch assembly, rear R.H.

1
Ex VAT: £184.87
Inc VAT: £221.84

AK17
850425

CLICK FOR
MORE INFO

Wheelarch assembly, rear L.H.

1
Ex VAT: £254.61
Inc VAT: £305.53

AK18
850121

CLICK FOR
MORE INFO

Panel, closing, rear wheelarch R.H.

Call for price and availability

1
Ex VAT: £258.50
Inc VAT: £310.20

AK19
850120

CLICK FOR
MORE INFO

Panel, closing, rear wheelarch L.H.

Call for availabilty. Not currently available

1
Ex VAT: £258.50
Inc VAT: £310.20

AK19A
850429

CLICK FOR
MORE INFO

Housing, rear lamp, and closing pocket assembly R.H.

1
Ex VAT: £61.25
Inc VAT: £73.50

AK20
850428

CLICK FOR
MORE INFO

Housing, rear lamp, and closing pocket assembly L.H.

1
Ex VAT: £61.25
Inc VAT: £73.50

AK21
650166

CLICK FOR
MORE INFO

Bracket, support, tank to wheelarch R.H.

Consider also second hand part 650166SH.

1
Ex VAT: £22.74
Inc VAT: £27.29

AK22
650165

CLICK FOR
MORE INFO

Bracket, support, tank to wheelarch L.H.

Consider also second hand part 650165SH.

1
Ex VAT: £22.74
Inc VAT: £27.29

AK23
850476

CLICK FOR
MORE INFO

REAR WING ASSEMBLY R.H.

Steel TR4, 4A, 250 and 5 Rear Outer Wing right hand.

1
Ex VAT: £516.67
Inc VAT: £620.00

AK24
850475

CLICK FOR
MORE INFO

REAR WING ASSEMBLY L. H.

Steel TR4, 4A, 250 and 5 Rear Outer Wing left hand.

1
Ex VAT: £516.67
Inc VAT: £620.00

AK24A
HU0706P

CLICK FOR
MORE INFO

Screw, set Rear wing to 'B' post attachment

This item has been superceded by HU706P - see below

6
HU706P
SCREW 1/4UNF x 3/4 CSK POINTED

6
Ex VAT: £0.67
Inc VAT: £0.80

AK24B
WM0057

CLICK FOR
MORE INFO

Washer, plain Rear wing to 'B' post attachment

This item has been superceded by WP10412057 - see below

6
WP10412057

CLICK FOR
MORE INFO

WASHER 1/4 X 3/4 INCH OD

6
Ex VAT: £0.24
Inc VAT: £0.29

AK24C
WQ0307

CLICK FOR
MORE INFO

Washer, lock , Rear wing to 'B' post attachment

This item has been superceded by WS104070643 - see below

6
WS104070643
WASHER SPRING 1/4" RECT SECTION

6
Ex VAT: £0.13
Inc VAT: £0.16

AK24D
UL2705

CLICK FOR
MORE INFO

Screw, acme Rear wing to tonneau and deck

16
Ex VAT: £0.33
Inc VAT: £0.40

AK24E
WM0057

CLICK FOR
MORE INFO

Washer, plain Rear wing to tonneau and deck

This item has been superceded by WP10412057 - see below

16
WP10412057

CLICK FOR
MORE INFO

WASHER 1/4 X 3/4 INCH OD

16
Ex VAT: £0.24
Inc VAT: £0.29

AK24F
FA3058

CLICK FOR
MORE INFO

Nut, fix Rear wing to tonneau and deck

This item has been superceded by FJ24074 - see below

16
FJ24074
WING CLIP (SPIRENUT)

16
Ex VAT: £0.46
Inc VAT: £0.55

AK24G
UL2705

CLICK FOR
MORE INFO

Screw, acme Wing to closing panel and rear valance

2
Ex VAT: £0.33
Inc VAT: £0.40

AK24H
WM0057

CLICK FOR
MORE INFO

Washer, plain Wing to closing panel and rear valance

This item has been superceded by WP10412057 - see below

2
WP10412057

CLICK FOR
MORE INFO

WASHER 1/4 X 3/4 INCH OD

2
Ex VAT: £0.24
Inc VAT: £0.29

AK14I
FA3058

CLICK FOR
MORE INFO

Nut, fix Wing to closing panel and rear valance

This item has been superceded by FJ24074 - see below

2
FJ24074
WING CLIP (SPIRENUT)

2
Ex VAT: £0.46
Inc VAT: £0.55

AK24J
UL2705

CLICK FOR
MORE INFO

Screw, acme Wing to rear valance

4
Ex VAT: £0.33
Inc VAT: £0.40

AK24K
WM0057

CLICK FOR
MORE INFO

Washer, plain Wing to rear valance

This item has been superceded by WP10412057 - see below

4
WP10412057

CLICK FOR
MORE INFO

WASHER 1/4 X 3/4 INCH OD

4
Ex VAT: £0.24
Inc VAT: £0.29

AK24L
FA3058

CLICK FOR
MORE INFO

Nut, fix Wing to rear valance

This item has been superceded by FJ24074 - see below

4
FJ24074
WING CLIP (SPIRENUT)

4
Ex VAT: £0.46
Inc VAT: £0.55

AK24M
UL2705

CLICK FOR
MORE INFO

Screw, acme Wing to sill panel

2
Ex VAT: £0.33
Inc VAT: £0.40

AK24N
WPOO07
Washer, plain Wing to sill panel

2
AK24O
FA3058

CLICK FOR
MORE INFO

Nut, fix Wing to sill panel

This item has been superceded by FJ24074 - see below

2
FJ24074
WING CLIP (SPIRENUT)

2
Ex VAT: £0.46
Inc VAT: £0.55

AK24P
608522

CLICK FOR
MORE INFO

Clip, wing to lamp housing

This item has been superceded by ANK5046A - see below

4
ANK5046A
SEAT COVER CLIP

4
Ex VAT: £0.36
Inc VAT: £0.43

AK25
850346

CLICK FOR
MORE INFO

REAR DECK ASSEMBLY

This item has been superceded by 806820 - see below

1
806820

CLICK FOR
MORE INFO

REAR DECK ASSEMBLY

TR4 Rear Deck Assembly. From CT5643 incorporating two forward panels, a centre panel and two rear panels either side of the boot lid.
Remarks: Fitted up to Commission No. CTS642 only

1
AK25A
617975

CLICK FOR
MORE INFO

Rivnut

This item has been superceded by 617975RP - see below


617975RP
BLIND NUT FASTENER

Ex VAT: £3.00
Inc VAT: £3.60

AK25B
806820

CLICK FOR
MORE INFO

REAR DECK ASSEMBLY

TR4 Rear Deck Assembly. From CT5643 incorporating two forward panels, a centre panel and two rear panels either side of the boot lid.
Remarks: Fitted from Commission No. CT5643 and future

1
AK26
850008

CLICK FOR
MORE INFO

Tonneau side, upper R.H.

TR4, 4A, 250 and 5 Right Hand Rear Deck Panel, steel; the part of the rear deck that sits to the left of the boot lid.

1
Ex VAT: £178.50
Inc VAT: £214.20

AK27
850007

CLICK FOR
MORE INFO

Tonneau side, upper L.H.

TR4, 4A, 250 and 5 Left Hand Rear Deck Panel, steel; the part of the rear deck that sits to the left of the boot lid.

1
Ex VAT: £178.50
Inc VAT: £214.20

AK28
650219

CLICK FOR
MORE INFO

Bracket, catch, trunk lid stay

Small support used with fixed boot lid stay. Not available new or second hand. The later part used with the sliding boot lid stay is 612487.

1
AK28A
750180

CLICK FOR
MORE INFO

Gusset, '13' post, top R.H.

This part has no tapped plate but has a round hole in the centre. It is not available, use 708094

1
AK29
750179

CLICK FOR
MORE INFO

Gusset, '13' post, top L.H.

This part has no tapped plate but has a round hole in the centre. It is not available, use 708093

1
AK30
850379

CLICK FOR
MORE INFO

REAR VALANCE ASSEMBLY

VALENCE REAR. TR4/5

1
AK31
950097

CLICK FOR
MORE INFO

Floor, panel, main R.H.

This item has been superceded by 904006 - see below

1
904006

CLICK FOR
MORE INFO

FLOOR RH TR4-6

TR4A-6 RH floor panel (also use for TR4).

1
Ex VAT: £151.67
Inc VAT: £182.00

AK32
950096

CLICK FOR
MORE INFO

Floor, panel, main L.H.

This item has been superceded by 904005 - see below

1
904005

CLICK FOR
MORE INFO

FLOOR LH TR4-6

TR4A-6 LH floor panel (also use for TR4).

1
Ex VAT: £151.67
Inc VAT: £182.00

AK33
750027

CLICK FOR
MORE INFO

Bracket, sill mounting

4
Ex VAT: £10.67
Inc VAT: £12.80

AK34
850434

CLICK FOR
MORE INFO

Tunnel, propshaft assembly

This item has been superceded by 808230 - see below

1
808230

CLICK FOR
MORE INFO

HANDBRAKE TUNNEL 4-6

Consider second hand part 808230SH

1
Ex VAT: £160.86
Inc VAT: £193.03

AK35
805686

CLICK FOR
MORE INFO

Cover assembly, gearbox

This item has been superceded by 713569FG - see below

1
713569FG

CLICK FOR
MORE INFO

GEARBOX TUNNEL FIBREGLASS TR4-6

TR4-6 fibreglass transmission tunnel. You may need a fitting kit 713569FK (consisting of all the screws and plates needed to fit the gearbox cover) and a seal kit 713569GS.

1
Ex VAT: £83.80
Inc VAT: £100.56

AK36
805674

CLICK FOR
MORE INFO

Seal, rubber, cover to floor R.H.

This item has been superceded by RTR5304 - see below

1
RTR5304

RTR Upgrade

RUBBER C SEC SOFT 30x20x3MM 2 M

1
Ex VAT: £9.76
Inc VAT: £11.71

AK37
805673

CLICK FOR
MORE INFO

Seal, rubber, cover to floor L.H.

This item has been superceded by RTR5304 - see below

1
RTR5304

RTR Upgrade

RUBBER C SEC SOFT 30x20x3MM 2 M

1
Ex VAT: £9.76
Inc VAT: £11.71

AK38
805684

CLICK FOR
MORE INFO

Seal, rubber Cover to bulkhead centre panel

This item has been superceded by RTR5303 - see below

1
RTR5303

RTR Upgrade

RUBBER STRIP SOFT "P"SEC. 1.3M

1
Ex VAT: £3.72
Inc VAT: £4.46

AK39
705758

CLICK FOR
MORE INFO

Seal, rubber Cover to propshaft tunnel

This item has been superceded by RTR5303 - see below

1
RTR5303

RTR Upgrade

RUBBER STRIP SOFT "P"SEC. 1.3M

1
Ex VAT: £3.72
Inc VAT: £4.46

AK39A
HU0706

CLICK FOR
MORE INFO

Screw, set Gearbox cover to floor

This item has been superceded by SH604061 - see below

10
SH604061

CLICK FOR
MORE INFO

SCREW 1/4 UNF X 3/4 INCH

10
Ex VAT: £0.16
Inc VAT: £0.19

AK39B
612286

CLICK FOR
MORE INFO

Washer, plate Gearbox cover to floor

9
Ex VAT: £1.38
Inc VAT: £1.66

AK39C
WM0057

CLICK FOR
MORE INFO

Washer, plain Gearbox cover to floor

This item has been superceded by WP10412057 - see below

1
WP10412057

CLICK FOR
MORE INFO

WASHER 1/4 X 3/4 INCH OD

1
Ex VAT: £0.24
Inc VAT: £0.29

AK39D
HU0706

CLICK FOR
MORE INFO

Screw, set Gearbox cover to bulkhead centre panel

This item has been superceded by SH604061 - see below

7
SH604061

CLICK FOR
MORE INFO

SCREW 1/4 UNF X 3/4 INCH

7
Ex VAT: £0.16
Inc VAT: £0.19

AK39E
WM0057

CLICK FOR
MORE INFO

Washer, plain Gearbox cover to bulkhead centre panel

This item has been superceded by WP10412057 - see below

7
WP10412057

CLICK FOR
MORE INFO

WASHER 1/4 X 3/4 INCH OD

7
Ex VAT: £0.24
Inc VAT: £0.29

AK39F
FQ3405

CLICK FOR
MORE INFO

Nut, captive and retainer Gearbox cover to bulkhead centre panel

This item has been superceded by 518454X - see below

7
518454X
CAGED CLIP NUT-1/4

7
Ex VAT: £1.38
Inc VAT: £1.66

AK42
850397

CLICK FOR
MORE INFO

Heelboard

1
Ex VAT: £74.56
Inc VAT: £89.47

AK43
566601

CLICK FOR
MORE INFO

Seat, pan assembly, occasional seat

This item has been superceded by 910065 - see below

1
910065

CLICK FOR
MORE INFO

REAR PASS FLOOR 4-6

Consider bracket under the floor part number 950008 (TR250, 5 and 6 only) and aluminium part 910065AL

1
Ex VAT: £239.67
Inc VAT: £287.60

AK43A
650272

CLICK FOR
MORE INFO

Bracket, support, squab, bottom R.H.

TR4, 4A, 250, 5, 6 Horizontal Tank Board Angled Support Right hand welded to the triangular Gusset Panel and rear floor.

1
Ex VAT: £0.93
Inc VAT: £1.12

AK44
650271

CLICK FOR
MORE INFO

Bracket, support, squab, bottom L.H.

TR4, 4A, 250, 5, 6 Horizontal Tank Board Angled Support Left Hand welded to the triangular Gusset Panel and rear floor.

1
Ex VAT: £0.93
Inc VAT: £1.12

AK45
850471

CLICK FOR
MORE INFO

Floor panel assembly, side, rear R.H.

1
Ex VAT: £182.00
Inc VAT: £218.40

AK46
850470

CLICK FOR
MORE INFO

Floor panel assembly, side, rear L.H.

1
Ex VAT: £182.00
Inc VAT: £218.40

AK47
750022

CLICK FOR
MORE INFO

Bracket, mounting, rear

2
Ex VAT: £41.01
Inc VAT: £49.21

AK48
850387

CLICK FOR
MORE INFO

Pan, spare wheel assembly

1
Ex VAT: £186.82
Inc VAT: £224.18
