SUPPORT BRACKET DASH CPTR6

Part No:
815721

TR6 to CF1 Facia support often known as the 'H' frame. It has flattened upper sides to accommodate kidney panels and no switch holes.

As this part is not available new, consider second hand part 815721SH, 821571SH or one of the covers listed below
RTR6007 RTR6007L 808682SH 815721SH 808682X 812001X 821551X 815721X

There were 4 separate part numbers for the 'H' frame fitted to TR4A to TR6 although they are all basically the same part.
808682 TR4A has rounded upper sides and 3 heater control holes
812001 TR250, 5 has rounded upper sides and no switch holes
815721 TR6 to CF1 has flattened upper sides to accommodate kidney panels and no switch holes
821571 TR6 from CR1 has flattened upper sides to accommodate kidney panels and one hole for the interior light switch.
821551 TR6 from CF1 USA version

None of these parts are available new so we offer second hand parts and three types of black cover.
808682SH we keep second hand 808682 and 812001 under this number
815721SH we keep second hand 815721, 821551 and 821571 under this number

808682X is a plastic cover that suits 808682
812001X is a plastic cover that suits 812001
815721X is a plastic cover that suits 815721
821551X is a plastic cover that suits 821571 and 821551
RTR6007 is a vinyl cover that is stitched together from 4 parts and suits all types
RTR6007L is a leather cover that is stitched together from 4 parts and suits all types
